A36 Welded ERW Casing CS Ms Hot Rolled Drawn Pipe
A36 Welded CS Pipe
A36 carbon steel structural pipe

A36 Carbon Steel Pipe for Structural

A36 steel pipe is an internationally used low-carbon structural steel pipe, widely used in construction, machinery manufacturing, bridge engineering and other fields.

Send Inquiry

Chat Now

Product Introduction

A36 Carbon Steel Pipe for Structural Description

A36 Steel Pipe is a carbon structural steel used to manufacture welded and bolted metal structures for industrial and civil construction and bridge construction. ASTM A36 Steel Pipe is also used to manufacture products and parts for general construction and mechanical engineering purposes.

1. Chemical composition standard (ASTM A36)

The typical composition of A36 steel plate is:
Carbon (C) ≤ 0.26%
Manganese (Mn) 0.60%-1.20%
Phosphorus (P) ≤ 0.04%
Sulfur (S) ≤ 0.05%
Its low-carbon design takes into account both weldability and plasticity. The manganese element improves strength while maintaining cold bending performance, which meets the strict requirements of ASTM A36 standard for building structural steel.

2. Mechanical performance indicators
Yield strength: ≥ 250 MPa
Tensile strength: 400-550 MPa
Elongation (gauge length 200mm): ≥ 20%
Experimental data show that A36 steel plate can still maintain good toughness in -30℃ low-temperature impact test, which is suitable for engineering environments with large temperature differences.

3. Quality control points

Raw material inspection: check the Mn/C ratio in the steel mill's warranty (should be > 2.5)
Ultrasonic flaw detection: detect internal defects according to ASTM A435 standard
Hardness sampling: Brinell hardness HB should be controlled in the range of 137-180

A36 Carbon Steel Pipe specification

Products	LSAW Steel Pipe
Surface Treatment	1. Galvanized 2. Black and color painting 3. Transparent oil,anti-rust oil 4. According to clients requirement
Alloy Or Not	Non-Alloy
Size	DN15-600mm
Thickness	2- 20 mm(accroding to the buyer's request)
Length	12m, 6m, 1-12m(accroding to the buyer's request)
Standard	ASTM A53, API 5L, ASTM A252, ASTM A795, ISO65, DIN2440, BS1387. BS1139, EN10255, EN39, JIS3444, GB/T 3091 & GB/T13793
Certificate	API, CE, BSI, JIS
Pipe Ends	Bevelled or plain ends.
End Protection	With or Without caps(accroding to the buyer's request)
Packing	Packed in bundles with nylon slings or piece by piece
Brand	GNEE
Place Of Origin	Tianjin, China
Trade Terms:	FOB/ CIF/ CFR / FCA / EXW
Delivery Time:	15-45 days (based on quantity) after receiving advanced payment by T/T or LC .
Payment Terms:	T/T or L/C
Main Market:	Southeast Asia, South Asia, Middle East, Middle&South Americ, Africa and Oceania
