Q235 Thin-walled Welded Steel Pipe
Material Standard: GB/T 700 Q235B
Diameter Range: Φ10mm-Φ219mm
Wall Thickness Range: 0.8mm-3.0mm
Fixed Length: 6 meters (customizable)
Execution Standards: GB/T 13793, GB/T 3091
Q235B Thin-Walled Welded Steel Pipe Product Introduction
Q235B thin-walled welded steel pipe is a thin-walled welded steel pipe manufactured using Q235B carbon structural steel as raw material and high-frequency welding (ERW) process. This product features light weight, high strength, and low cost, and is widely used in furniture, decoration, agricultural machinery, and other fields where material weight and cost are critical.
Performance Characteristics of Q235B Thin-Wall Welded Steel Pipe
| Performance Category | Specific Indicator | Technical Specification | Testing Standard |
|---|---|---|---|
| Mechanical Properties | Yield Strength | ≥235 MPa | GB/T 228.1 |
| Tensile Strength | 375-500 MPa | GB/T 228.1 | |
| Elongation After Fracture | ≥26% | GB/T 228.1 | |
| Hardness | ≤160 HB | GB/T 230.1 | |
| Geometric Characteristics | Outer Diameter Tolerance | ±0.2 mm | GB/T 13793 |
| Wall Thickness Tolerance | ±0.1 mm | GB/T 13793 | |
| Ovality | ≤0.3% D | GB/T 13793 | |
| Straightness | ≤1.5 mm/m | GB/T 13793 |
Quality Inspection Process of Q235B Thin-Walled Welded Steel Pipes
First, the chemical composition and mechanical properties of the Q235B steel strip are randomly sampled and inspected. During the welding process, eddy current testing is used to conduct 100% online inspection of the weld seam to ensure there are no defects such as incomplete penetration or slag inclusions. Finished products must be sampled according to standards and subjected to a flattening test until no cracks are found, followed by a hydrostatic test to verify pressure resistance and sealing. Finally, all geometric dimensions such as outer diameter, wall thickness, and ovality are fully inspected to ensure tolerances meet the requirements of GB/T 13793 standard. All test data are recorded and archived to achieve quality traceability.
About us
GNEE STEEL supplies Q235B thin-walled welded steel pipes to the global market. Our products are manufactured under rigorous quality control processes, including comprehensive testing of mechanical properties, dimensional accuracy, and weld integrity to ensure compliance with international standards such as GB/T, ASTM, and EN. We can flexibly customize diameters, wall thicknesses, and surface treatments (e.g., galvanizing, painting) to meet different project requirements.
