Name: EN 10217 P195 TR1 ERW Tubes - China EN 10217 P195 TR1 ERW Tubes Manufacturers Suppliers - GNEE Pipe
Brand: GNEE
SKU: 239904769

Type：Welded Steel Pipe
Model Number: EN10217-1
Delivery Time : 4-6 weeks

Send Inquiry

Chat Now

Product Introduction

We are always at your service when you need

The GNEE Group is a renowned Chinese manufacturer and supplier of EN10217-1 P195 TR1 electric resistance welded pipes. Our EN10217-1 P195 TR1 non-alloy welded pipes are suitable for use in pressure environments. The diameter of the EN10217 P195 TR1 pressure welded pipes we produce ranges from 17.2mm to 2020mm, with wall thicknesses up to 17.5mm. If you require EN10217 P195 TR1 carbon steel welded pipes in other sizes, we can also accommodate your needs. For more information, please feel free to contact us at any time.

35000+

Square Meters Built

16+

years experience

200+

Enterprise Employees

600+

Cooperating Partner

EN10217-1 P195 TR1 Welding Steel Pipe Specification

Standard:	EN10217-1	Material:	Fine Grain Steel
Type:	ERW Welded Steel Tube	Shape:	Round
Payment Terms	T/T, L/C	Terms of Trade	FOB, CFR, CIF, DDP, EXW
Surface:	Black And Weld Seam Removed
Types:	welding steel tubing electric resistance welded steel tube

P195 TR1 ERW Pipe Chemical Composition

Steel Grade		C max.	Si max.	Mn max.	P max.	S max.	Cr b Max.	Mo b max.	Ni b max.	Al tot min.	Cu b c max.	Nb b max.	Ti b max.	V b max.	Cr+Cu+Mo+Ni b max.
Steel Name	Steel Number	C max.	Si max.	Mn max.	P max.	S max.	Cr b Max.	Mo b max.	Ni b max.	Al tot min.	Cu b c max.	Nb b max.	Ti b max.	V b max.	Cr+Cu+Mo+Ni b max.
P195TR1	1.0107	13	35	70	25	20	30	8	30	–	30	10	4	2	70
a Elements not included in this Table shall not be intentionally added to the steel without the agreement of the purchaser, except for elements which may be added for finishing the cast. All appropriate measures shall be taken to prevent the addition of undesirable elements from scrap or other materials used in the steel making process.
b The content of these elements need not be reported unless intentionally added to the cast.
c Option 3: In order to facilitate subsequent forming operation, an agreed maximum copper content lower than indicated and an agreed specified maximum tin content shall apply.
d This requirement is not applicable provided the steel contains a sufficient amount of other nitrogen binding elements, which shall be reported.

Mechanical Property of EN10217-1 P195 TR1 Welded Carbon Steel Pipe

Steel Grades		Tensile Properties					Impact Properties
Steel Name	Steel Number	Upper Yield Strength		Tensile Strength	Elongation		Minimum Average
		Reh b min for		Tensile Strength	A min		Absorbed Energy KV J
		T mm		Rm	% b c		at a temperature of ℃ c
		T ≤16	16＜T≤40		% b c		l		t
		MPa *		MPa *	l	t	0	-10	0
P195TR1 e	1.0107	195	185	320-440	27	25	–	–	–
a For wall thickness greater than 40 mm the mechanical properties are subject to agreement. b See 11.2. c l = longitudinal; t = transverse. d Option 5: Additionally, longitudinal impact strength shall be verified at – 10 °C. e Tubes made to these material grades are unlikely to support the essential requirements of Directive 97/23/EC unless other criteria are taken into account, see Annex I section 7.5 of this Directive * 1 MPa = 1 N/mm²

EN10217 P195 TR1 Welded Steel Tubes For Pressure Purposes

P195 TR1 welded steel pipe P195 TR1 electric resistance welded tube

GNEE P195 TR1 Welded Tubing for Sale

EN10217-1 P195 TR1 LSAW Pipe	EN10217-1 P195 TR1 High Frequency Welded Pipe
EN10217-1 P195 TR1 ERW Carbon Steel Pipe	EN10217-1 P195 TR1 Spiral Welded Tube
EN10217-1 P195 TR1 High Frequency Welded Pipe	EN10217-1 P195 TR1 Welded Pressure Pipes
EN10217-1 P195 TR1 Welding Round Pipe	EN10217-1 P195 TR1 Electric Welded Non-alloy Steel Tubes

FAQ

Q: Do you accept customization of erw pipes?

A: Yes, but customers are required to provide detailed information such as size, quantity, material, etc. of customized erw steel pipe.

Q: What should I do if the pipes I receive are defective?

A: We can raise samples for you before the order is shipped. If the pipes you receive do not match the samples, we will refund you or you can choose to reissue the pipes.

Q: Are you a manufacturer or trader?

A: GNEE Group is a trading company with 16 years of experience in producing and supplying steel products. We have 20 steel pipe production lines and 5 pipe fitting production lines. Can provide you with customized services. You are welcome to visit our factory and company.

Q: Can you provide samples? Are there any fees?

A: We can provide you with pipe fitting samples, but the logistics costs need to be paid by the customer.

Q: What is the delivery time of Welded Steel Tubes?

A: Spot delivery time: 3-7 days after receiving advance payment.

Customized delivery time: 20-30 days after order confirmation.

Q: What is your minimum order quantity of pipes?

A: For regular sized welded tubing, we have a large stock of tubes in stock with no MOQ required. For custom sizes, the MOQ is 30 tonnes.

Q: What is your payment term?

A: Our payment terms are L/L, T/C.

Q: What is your term of trade?

A: Our terms of trade are FOB, CIF, CFR, DDP, EXW.
