Finned tubes are a type of tubing with a special structure, featuring a series of thin, dense metal fins attached to their surface. These fins significantly enhance the heat dissipation performance of the tube surface, thereby improving the heat transfer capacity of the entire system.

Send Inquiry

Chat Now

Product Introduction

Finned tubes for heat exchangers, also known as heat exchanger tubes, are heat exchange elements used to enhance heat transfer. They improve heat exchange efficiency by increasing surface area and are suitable for high-temperature, high-pressure, and corrosive environments in industries such as boilers, power generation, and metallurgy. Their core function is to reduce contact thermal resistance and possess corrosion-resistant and wear-resistant properties, making them commonly used in waste heat recovery and heat exchange equipment.

Manufacturing processes include high-frequency welding and three-roll skew rolling. High-frequency welded spiral finned tubes are widely used due to their high degree of automation, while three-roll skew rolling achieves seamless bonding through integral rolling. Finned tubes are classified by process (rolled, welded, etc.) and by fin shape (spiral, longitudinal, etc.).

Materials include copper, aluminum, and steel, and they can be adapted for applications such as air cooling and waste heat recovery. Tube bundle arrangements are divided into staggered (high heat exchange efficiency) and linear (low resistance) arrangements. The tube box structure design needs to be adjusted in conjunction with fluid pressure and temperature difference.

Carbon Steel Fins Size：

Tube OD	Fin Height	Fin Thickness	Fins Per Inch
3/8	1/4	.015	4, 5, 6, 7, 8, 9, 10
1/2	1/4	.015	4, 5, 6, 7, 8, 9, 10
	3/8	.015	4, 5, 6, 7, 8, 9, 10
5/8	1/4	.015	4, 5, 6, 7, 8, 9, 10
	3/8	.015	4, 5, 6, 7, 8, 9, 10
3/4	1/4	.015	4, 5, 6, 7, 8, 9, 10
	3/8	.015	4, 5, 6, 7, 8, 9, 10
	1/2	.030	4, 5, 6, 7, 8
1	1/4	.015	4, 5, 6, 7, 8, 9, 10
	3/8	.015	4, 5, 6, 7, 8, 9, 10
	1/2	.030	4, 5, 6, 7, 8
	5/8	.030	2, 3, 4, 5, 6
1 1/4	3/8	.015	4, 5, 6, 7, 8, 9, 10
	1/2	.030	4, 5, 6, 7, 8
	5/8	.030	2, 3, 4, 5, 6
1 1/2	1/2	.030	2, 3, 4, 5, 6, 8
	5/8	.030	2, 3, 4, 5, 6
	3/4	.040	2, 3, 4, 5, 6
1 3/4	5/8	.040	2, 3, 4, 5, 6
	3/4	.040	2, 3, 4, 5, 6
2	3/4	.040	2, 3, 4, 5, 6
	1	.040	2, 3, 4, 5, 6

Copper Fins size：

Tube OD	Fin Height	Fin Thickness	Fins Per Inch
1/4	3/16	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16, 18
3/8	3/16	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16, 18
	1/4	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16
1/2	3/16	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16, 18
	1/4	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16
	3/8	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14
5/8	3/16	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16, 18
	1/4	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16
	3/8	.015	2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16, 18
	1/2	.020	4, 5, 6, 7, 8, 9, 10
3/4	1/4	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16
	3/8	.015	2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16
	1/2	.020	4, 5, 6, 7, 8, 9, 10
1	1/4	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14
	3/8	.015	2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16, 18, 20
	1/2	.020	4, 5, 6, 7, 8, 9, 10
	5/8	.020	4, 5, 6, 7, 8, 9, 10
1 1/4	3/8	.015	4, 5, 6, 7, 8, 9, 10, 11, 12
	1/2	.020	4, 5, 6, 7, 8, 9, 10
	5/8	.020	4, 5, 6, 7, 8, 9, 10
1 1/2	3/8	.015	4, 5, 6, 7, 8, 9, 10, 11, 12
	1/2	.020	4, 5, 6, 7, 8, 9, 10
	5/8	.020	4, 5, 6, 7, 8, 9, 10
	3/4	.030	4, 5, 6, 7, 8
1 3/4	5/8	.020	4, 5, 6, 7, 8
	3/4	.030	4, 5, 6, 7, 8
2	3/4	.030	4, 5, 6, 7, 8
	1	.030	3, 4, 5, 6, 7

Stainless Fins size：

Tube OD	Fin Height	Fin Thickness	Fins Per Inch
1/4	3/16	.015	4, 5, 6, 7, 8, 9, 10
3/8	3/16	.015	4, 5, 6, 7, 8, 9, 10
	1/4	.015	4, 5, 6, 7, 8, 9, 10
1/2	3/16	.015	4, 5, 6, 7, 8, 9, 10
	1/4	.020	4, 5, 6, 7, 8, 9, 10
	3/8	.020	4, 5, 6, 7, 8, 9, 10
5/8	3/16	.020	4, 5, 6, 7, 8, 9, 10
5/8	1/4	.020	4, 5, 6, 7, 8, 9, 10
5/8	3/8	.020	4, 5, 6, 7, 8, 9, 10
3/4	3/16	.015	4, 5, 6, 7, 8, 9, 10
	1/4	.020	4, 5, 6, 7, 8, 9, 10
	3/8	.020	4, 5, 6, 7, 8, 9, 10
	1/2	.020	2, 3, 4, 5, 6
1	1/4	.020	4, 5, 6, 7, 8, 9, 10
	3/8	.020	4, 5, 6, 7, 8, 9, 10
	1/2	.020	2, 3, 4, 5, 6, 7, 8
	5/8	.030	2, 3, 4, 5, 6
1 1/4	3/8	.020	4, 5, 6, 7, 8, 9, 10
	1/2	.020	2, 3, 4, 5, 6, 7, 8
	5/8	.020	2, 3, 4, 5, 6
1 1/2	1/2	.020	2, 3, 4, 5, 6
	5/8	.020	2, 3, 4, 5, 6
	3/4	.020	2, 3, 4, 5, 6
1 3/4	5/8	.020	2, 3, 4, 5, 6
	3/4	.020	2, 3, 4, 5, 6
2	3/4	.020	2, 3, 4, 5, 6

Aluminum Fins size：

Tube OD	Fin Height	Fin Thickness	Fins Per Inch
1/4	3/16	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16, 18
3/8	3/16	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16, 18
	1/4	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16
1/2	3/16	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16, 18
	1/4	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16
	3/8	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14
5/8	3/16	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16, 18
5/8	1/4	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16
5/8	3/8	.015	4, 5, 6, 7, 8, 9, 10, 11, 12
5/8	1/2	.020	4, 5, 6, 7, 8, 9, 10
3/4	1/4	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14, 16
	3/8	.015	4, 5, 6, 7, 8, 9, 10, 11, 12
	1/2	.020	4, 5, 6, 7, 8, 9, 10
1	1/4	.015	4, 5, 6, 7, 8, 9, 10, 11, 12, 14
	3/8	.015	4, 5, 6, 7, 8, 9, 10, 11, 12
	1/2	.020	4, 5, 6, 7, 8, 9, 10
	5/8	.020	4, 5, 6, 7, 8, 9, 10
1 1/4	3/8	.015	4, 5, 6, 7, 8, 9, 10, 11, 12
	1/2	.020	4, 5, 6, 7, 8, 9, 10
	5/8	.020	4, 5, 6, 7, 8, 9, 10
1 1/2	3/8	.015	4, 5, 6, 7, 8, 9, 10, 11, 12
	1/2	.020	4, 5, 6, 7, 8, 9, 10
	5/8	.020	4, 5, 6, 7, 8, 9, 10
	3/4	.030	4, 5, 6, 7, 8
1 3/4	5/8	.020	4, 5, 6, 7, 8
	3/4	.030	4, 5, 6, 7, 8
2	3/4	.030	4, 5, 6, 7, 8
	1	.030	3, 4, 5, 6, 7
